GL Product Videos & Demos



Hanging out with RCR:
The Evolution of Voice Testing
Hanging out with RCR:
LTE, VoLTE and the Path to 5G
Hanging out with RCR:
GL Communications and Small Cell Testing


RCR Wireless NEWS
00:28:14


RCR Wireless NEWS
00:06:02


RCR Wireless NEWS
00:13:34


Echo Measurement Utility (EMU) Training Video Echo Canceller Testing in TDM and IP Networks PacketCheck™ - Software Ethernet Tester


00:09:44


00:13:32


00:11:57



LightSpeed1000™ OC-3/STM-1 and OC-12/STM-4 Analysis & Emulation


LightSpeed1000™ hardware platform (PCIe Card and USB Pod)
00:08:17




Wireless Networks (2G, 3G, 4G Lab Simulation)


4G VoLTE Call Simualtion and Monitoring System
00:06:15


Wireless Networks - 2G Lab Simulation
00:03:28


Wireless Networks - 3G Lab Simulation
00:03:55


Wireless Networks - 4G Lab Simulation
00:04:50


Click to Play T1E1 Basic and Optional Applications

Multiplex and Demultiplex T1 E1 Lines
This software provides the capability to multiplex individual files on different timeslots into one aggregate output file and the reverse process of demultiplex one aggregate file into individual timeslot files. The program is applicable to T1/E1 multiplex systems and is a companion software for the files transmit and the files receive programs available with the T1/E1 cards.

Products Referred in Video : Mux-Demux software

00:07:44

Click to Play PacketScan™

PacketScan™ - All IP Analyzer - An Introduction
PacketScan™ - an All-IP Network Monitoring software  offers powerful features to capture and monitor live signaling and traffic over IP (version 4 and 6). It captures, segregates, monitors and collects statistics on all IP calls.

Products Referred in Video : PacketScan™

00:06:57

PacketScan™ Demo - Part 1 - Setup
Typical setup for deploying PacketScan as a probe in an All-IP Network.

Products Referred in Video : PacketScan™, MAPS™ SIP

00:01:41

PacketScan™ Demo - Part 2 - Call Generation MAPS SIP
GL's Message Automation & Protocol Simulation (MAPS™) designed for SIP testing can simulate User Agents (User Agent Client- UAC, User Agent Server-UAS), Proxy, Redirect, Registrar and Registrant servers.

Products Referred in Video : MAPS-SIP

00:03:25

PacketScan™ Demo - Part 3 - Packet Data Analysis
PDA is an outstanding tool for live monitoring of signaling and traffic over IP. Packet Data Analysis (PDA) is distributed with GL’s Packet Analyzers, allowing users to monitor live IP networks including capture, analysis, and reporting of every call in detail.
Graphs available are – Active Calls, Average Jitter, E-Model MOS/R-Factor/Packets Discarded, RTP Packets Summary, ladder diagram for T.38 based fax calls and call signaling, Gap, Jitter, Gap/Jitter Distribution, Wave and Spectral Display for media stream analysis, VoIP calls, and more.

Products Referred in Video : PacketScan™, Packet Data Analysis (PDA)

00:19:23

PacketScan™ Demo - Part 4 - PacketScan Features
PacketScan™'s ability to collect vital statistics about calls for theoretically infinite time. The ability of PacketScan™ to capture data is limited only by the hard disk capacity of the PC. It features rich graphics, ladder diagrams and CDRs (Call Detail Records).

Products Referred in Video : PacketScan™

00:09:26


Click to Play Message Automation & Protocol Simulation (MAPS™)

MAPS™ - Using Profiles
Profiles are used to provide the user configured values to the fields in the Messages (i.e., Message Template in MAPS™ SIP I) through variables which are going to change during the course of a call. An XML file defines a set of multiple profiles with varying parameter values that allow users to configure call instances in call generation and to receive calls.

Products Referred in Video : MAPS™

00:10:20

MAPS™ - Script
This video discusses the basics of scripts - non-event driven and event driven scripts, building scripts, important variables and commands.

Products Referred in Video : MAPS™

00:09:04

MAPS™ - Send, Receive, and Decode Commands
In this training video, we are introducing you to the basic commands used to achieve a protocol state machine. The message forwarding happens through SEND command. RECV instruction is executed when any message is received. To handle the call flow without the prior knowledge of incoming messages, the Message Handler and DECODE commands are used.

Products Referred in Video : MAPS™

00:07:24

Testing LTE IMS Networks
Simulation of various interfaces of LTE and IMS (S1, eGTP, Diameter interfaces), this includes simulation of signalling and traffic such as Voice over LTE (VoLTE)

Products Referred in Video : MAPS™ LTE-IMS

00:09:17
